SRGT TYPE WIRE CABLE 200C 600v UL 3568

SRGT TYPE WIRE CABLE 200C 600v UL 3568

Silicone Rubber Glass Braid /FEP Jacket
600 Volts, 200C, #18 AWG - 500 MCM
UL Style 3568 CSA : AWM Class 1 Group A/B



SRGT Wire Cable is used in environments where SRGT Wire Cable will come in contact with gas, oil, or chemicals. The SRGT  wire cable can be directly immersed in water. SRGT Wire Cable can  maintain circuit integrity in equipment where high temperature and/or hazardous conditions exist requiring flexible, heat resistant stranded conductors at 600 volts.

Type SRGT Wire Cable is a high temperature wire cable that is a single stranded conductor lead cable. SRGT Wire Cable can be used in environments where resistance to fluids and oil is needed. SRGT Wire Cable is a good choice when resistance to abrasion and flexibility is needed in a cable design in harsh tough environments such as refineries chemical plants and other harsh environments.

SRGT Wire Cable is commonly used in refineries chemical plants and well as steel plants factories to name a few harsh environments where the continuous ambient temp does not exceed 200C.

SRGT Wire Cable will in fire conditions,  maintain circuit integrity for more than approximately one hour.

SRGT Wire Cable Characteristics: SRGT has a flexible design. SRGT Wire Cable for use in circuits where circuit integrity is a critical consideration. SRGT Wire Cable has Fire Resistant Characteristics with low smoke characteristics.

SRGT Wire Cable has a good resistance to fluids and most acids and oil.


SRGT Wire Cable Maximum continuous cable conductor temp: 200C Dry.

SRGT Wire Cable is a good choice for cable that need to meet the requirements of harsh environments such as abrasion and may resist cut throughs. SRGT Wire Cable is a good choice choice in harsh environments that have moisture.











SRGT TYPE WIRE CABLE 200C 600v UL 3568



AWG &

PART#

Stranding

Approximate Insulation
Thickness

Approximate Fiberglass
Braid

Approximate FEP Jacket
Thickness

Approximate Overall
Diameter

Approximate Weight
lbs/k ft

Temp
Rating

UL
Style


18 - SRGT 7/.0152 0.030 .005 0.010 0.140 15 200C 3568

16 - SRGT 7/.0192 0.030 .005 0.010 0.150 20 200C 3568

14 - SRGT 7/.0242 0.030 .005 0.010 0.165 30 200C 3568

12 -SRGT 19/.0179 0.030 .005 0.010 0.190 40 200C 3568

10 - SRGT 19/.0234 0.045 .005 0.010 0.245 60 200C 3568

8 - SRGT 54/.0179 0.060 .005 0.012 0.310 95 200C 3568

6 - SRGT 84/.0179 0.060 .005 0.012 0.350 130 200C 3568

4 - SRGT 133/.0177 0.060 .0075 0.012 0.430 190 200C 3568

2 - SRGT 133/.0223 0.060 .0075 0.012 0.500 280 200C 3568

1 - SRGT 259/.0177 0.080 .0075 0.017 0.600 375 200C 3568

1/0 - SRGT 259/.0202 0.080 .0075 0.017 0.640 455 200C 3568

2/0 - SRGT 259/.0229 0.080 .0075 0.017 0.700 555 200C 3568

3/0 - SRGT 259/.0255 0.080 .0075 0.017 0.755 680 200C 3568

4/0 - SRGT 259/.0286 0.080 .0075 0.017 0.820 825 200C 3568


Dimensions and weights shown are approximate and/or  nominal, subject to industry tolerances. All Data is Subject to Change Without Notice.

Inventory is subject to prior sale.  Product design, specifications & construction are subject to change without notice. Pictures are for general representational purposes and may not represent actual product.

Not Responsible for errors in print, verify all data with us or manufacturer.  Terms & Conditions of sale apply, for a copy contact us.

Products may be discontinued without notice.  Pricing Does Not Include Freight Costs. Minimum order dollar amount and/or quantity may be requested to meet minimum order requirements.



More Industrial Cable Solutions

High Temp Wire Index



1-800-843-6036

Click Here to Email Us

   OnLine Order



More Industrial Cable Solutions



SRGT Wire Cable is used in environments where SRGT Wire Cable will come in contact with gas, oil, or chemicals. The SRGT  wire cable can be directly immersed in water. SRGT Wire Cable can  maintain circuit integrity in equipment where high temperature and/or hazardous conditions exist requiring flexible, heat resistant conductors at 600 volts.

Type SRGT Wire Cable is a high temperature wire cable that is a single stranded conductor lead cable. SRGT Wire Cable can be used in environments where resistance to fluids and oil is needed. SRGT Wire Cable is a good choice when resistance to abrasion and flexibility is needed in a cable design used in harsh tough environments such as refineries chemical plants and other harsh environments.

SRGT Wire Cable is commonly used in refineries chemical plants and well as steel plants factories to name a few harsh environments where the continuous ambient temp does not exceed 200C.

SRGT Wire Cable is used in critical circuits in oil and chemical refineries and plants.
