Electronic Timer Switch Switches Fisher Pierce FE171C and FE174C. Fisher Pierce FE171C and FE174C Electronic Time Timer Switches are 7 Day and 24 Hour Electronic Time Timer Switch Switches. These Electronic Time Timer Switch Switches are ideal for automatic switch of motor loads and or lighting contactors. The Fisher Pierce FE171C and FE174C Electronic Timer Time Switch Switches are ideal for filtration systems, process equipment, gas station lighting, livestock feeders, building air circulation systems and security lighting.
|
7 Day and 24-Hour Electronic Time Timer Switch Switches The 7-day FE100C and FE171C are digital electronic, single channel time controls. They feature 16 events per day programmability for flexible daily schedules and include a skip days function Both units are easy to schedule and simple to understand as they represent the “set and forget” industry standard. Up to the minute scheduling and built in special capacitor carry-over is the low cost answer to reliable operation without spring-wound or battery carryover. Manual override switch is available for both models. Minimum ON/ OFF time for both units is 1 minute
|
Application Ideal for automatic, reliable-to-the minute switching of motor loads and/or lighting contactors which require exact timing (i.e. filtration systems, process equipment, gas station lighting, livestock feeders, building air circulation systems, security lighting etc.).
|
|
|
Operating Voltages: FE100C 120Vac FE171C 208-277Vac Switch Type :SPDT No Contacts Output Switch Ratings: - 20Amp resistive at 120Vac - 1hp at 120Vac, 2hp at 240Vac - 5 amp tungsten at 120-240Vac - 6 amp ballast at 120-277Vac, - 50/60hz Wiring Terminals: Accommodates from AWG #16 to AWG #10 wire. Operating Temperature Range: -400 to +1400 F
|
Enclosure: Case NEMA 1 drawn steel enclosure with lockable hasp. The case has round mounting holes on the back and combination knockouts (1/2" and ¾”) on each side, one on the bottom and one in the back. Shipping Weight: 2.0 lbs (0.9 kg) Dimensions: 8 1/8" H x 4 1/4" W x 3" D
|
||
|
Wiring Diagram
|
|||
|
