1000BASE-T SFP transceiver module for Category 5 copper
wire
OurPart Number:
MSGLC-T-ENC-18
OEM Part Number:
GLC-T
WEB PRICE EACH:
$81.00 |
Transceiver Specifications:
1000BASE-T SFP transceiver module for Category 5 copper
wire
| Connector Type: |
RJ45 |
| Cabling Options: |
Copper |
| Distance Support: |
Up To 100M |
| Data Transfer Rate: |
1 Gbps Gigabit Ethernet |
| Management: |
N/A |
| Frequency: |
N/A |
| Temperature: |
0°C to 70°C Operating Case Temperature
-40°C to 85° Storage Temperature |
| Form Factor: |
SFP (Small Form Factor Pluggable) MSA Compliant |
| Additional Information: |
Hot Swappable |
| Standard Warranty: |
Lifetime Replacement Warranty |
|
1000BASE-SX SFP 850nm MMF LC Connector
Our Part Number:
MSGLC-SX-MM-ENC-18
OEM Part Number:
GLC-SX-MM
WEB PRICE EACH:
$81.00 |
Transceiver Specifications:
1000BASE-SX SFP 850nm MMF LC Connector
| Interfaces/Ports: |
1 X 1000BASE-SX LAN |
| Connector Type: |
Duplex LC |
| Cabling Options: |
62.5 µm Multi-mode Fiber 1000Base-SX
50 µm Multi-mode Fiber 1000Base-SX |
| Distance Support: |
772 ft 62.5 µm Fiber 160 MHz
902 ft 62.5 µm Fiber 200 MHz
1640 ft 50.0 µm Fiber 400 MHz
1804 ft 50.0 µm Fiber 500 MHz |
| Data Transfer Rate: |
1 Gbps Gigabit Ethernet |
| Management: |
N/A |
| Frequency: |
850nm |
| Temperature: |
0°C to 70°C Operating Case Temperature
-40°C to 85° Storage Temperature |
| Form Factor: |
SFP (Small Form Factor Pluggable) MSA Compliant |
| Additional Information: |
Hot Swapable
Fiber Loss Budgets for 1000BASE-SX:
Transmit (dBm):
Max:-4
Min:-9.5
Receive (dBm):
Max:0
Min:-17
Operating Wavelength:
850 nm |
| Standard Warranty: |
Lifetime Replacement Warranty |
|
1000BASE-LX/LH SFP transceiver module for MMF and SMF, 1310-nm wavelength
Our Part Number:
MSGLC-LH-SM-ENC-18
OEM Part Number:
GLC-LH-SM
WEB PRICE EACH:
$81.00
|
Transceiver Specifications:
1000BASE-LX/LH SFP transceiver module for MMF and SMF, 1310-nm
wavelength
| Interfaces/Ports: |
1 x 1000BASE-LX LAN |
| Connector Type: |
DUPLEX LC |
| Cabling Options: |
62.5 µm Multi-mode Fiber 1000Base-SX
50 µm Multi-mode Fiber 1000Base-SX
9 µm Single-mode Fiber 1000Base-LX |
| Distance Support: |
Up To 10KM |
| Data Transfer Rate: |
1 Gbps Gigabit Ethernet |
| Management: |
N/A |
| Frequency: |
1310nm |
| Temperature: |
0°C to 70°C Operating Case Temperature
-40°C to 85° Storage Temperature |
| Form Factor: |
SFP (Small Form Factor Pluggable) MSA Compliant |
| Additional Information: |
Hot Swappable |
| Standard Warranty: |
Lifetime Replacement Warranty |
|
1000BASE-ZX SFP transceiver module for SMF, 1550-nm wavelength
Our Part Number:
MSGLC-ZX-SM-ENC-18
OEM Part Number:
GLC-ZX-SM
WEB PRICE EACH:
$181.00
|
Transceiver Specifications:
1000BASE-ZX SFP transceiver module for SMF, 1550-nm wavelength
| Interfaces/Ports: |
1 x 1000BASE-ZX LAN |
| Connector Type: |
DUPLEX LC |
| Cabling Options: |
9 µm Single-mode Fiber 1000Base-ZX |
| Distance Support: |
Up To 70KM |
| Data Transfer Rate: |
1 Gbps Gigabit Ethernet |
| Management: |
DOM |
| Frequency: |
1550nm |
| Temperature: |
0°C to 70°C Operating Case Temperature
-40°C to 85° Storage Temperature |
| Form Factor: |
SFP (Small Form Factor Pluggable) MSA Compliant |
| Additional Information: |
Hot Swappable |
| Standard Warranty: |
Lifetime Replacement Warranty |
|
1000BASE-BX10 SFP module for single-strand SMF, 1490-nm TX/1310-nm RX
Our Part Number:
MSGLC-BX-D-ENC-18
OEM Part Number:
GLC-BX-D
WEB PRICE EACH:
$218.00
|
Transceiver Specifications:
1000BASE-BX10 SFP module for single-strand SMF, 1490-nm TX/1310-nm RX
| Interfaces/Ports: |
1 x 1000BASE BX-D |
| Connector Type: |
SIMPLEX LC |
| Cabling Options: |
9 µm Single-mode Fiber 1000Base-BX |
| Distance Support: |
Up to 10KM |
| Data Transfer Rate: |
1 Gbps Gigabit Ethernet |
| Management: |
DOM |
| Frequency: |
1490nm TX/1310nm RX |
| Temperature: |
0°C to 70°C Operating Case Temperature
-40°C to 85° Storage Temperature |
| Form Factor: |
SFP (Small Form Factor Pluggable) MSA Compliant |
| Additional Information: |
Hot Swappable |
| Standard Warranty: |
Lifetime Replacement Warranty |
|
1000BASE-BX10 SFP module for single-strand SMF, 1310-nm TX/1490-nm RX
Our Part Number:
MSGLC-BX-U-ENC-18
OEM Part Number:
GLC-BX-U
WEB PRICE EACH:
$228.00
|
Transceiver Specifications:
1000BASE-BX10 SFP module for single-strand SMF, 1310-nm TX/1490-nm RX
| Interfaces/Ports: |
1 x 1000BASE BX-U |
| Connector Type: |
SIMPLEX LC |
| Cabling Options: |
9 µm Single-mode Fiber 1000Base-BX |
| Distance Support: |
Up To 10KM |
| Data Transfer Rate: |
1 Gbps Gigabit Ethernet |
| Management: |
DOM |
| Frequency: |
1310nm TX/1490nm RX |
| Temperature: |
0°C to 70°C Operating Case Temperature
-40°C to 85° Storage Temperature |
| Form Factor: |
SFP (Small Form Factor Pluggable) MSA Compliant |
| Additional Information: |
Hot Swappable |
| Standard Warranty: |
Lifetime Replacement Warranty |
|
|
1000BASE-SX SFP transceiver module for MMF, 850-nm wavelength, extended
operating temperature range and DOM support
Our Part Number:
MSSFP-GE-S-ENC-18
OEM Part Number:
SFP-GE-S
WEB PRICE EACH:
$63.00 |
Transceiver Specifications:
1000BASE-SX SFP transceiver module for MMF, 850-nm wavelength,
extended operating temperature range and DOM support
| Interfaces/Ports: |
1 x 1000BASE-SX LAN |
| Connector Type: |
DUPLEX LC |
| Cabling Options: |
62.5 µm Multi-mode Fiber 1000Base-SX
50 µm Multi-mode Fiber 1000Base-SX |
| Distance Support: |
772 ft 62.5 µm Fiber 160 MHz
902 ft 62.5 µm Fiber 200 MHz
1640 ft 50.0 µm Fiber 400 MHz
1804 ft 50.0 µm Fiber 500 MHz |
| Data Transfer Rate: |
1 Gbps Gigabit Ethernet |
| Management: |
DOM |
| Frequency: |
850nm |
| Temperature: |
-5°C to 85°C Operating Case Temperature
-40°C to 85°C Storage Temperature |
| Form Factor: |
SFP (Small Form Factor Pluggable) MSA Compliant |
| Additional Information: |
Hot Swappable |
| Standard Warranty: |
Lifetime Replacement Warranty |
|
|
1000BASE-LX/LH SFP transceiver module for MMF and SMF, 1300-nm wavelength,
extended operating temperature range and DOM support
Our Part Number:
MSSFP-GE-L-ENC-18
OEM Part Number:
SFP-GE-L
WEB PRICE EACH:
$76.00
|
Transceiver Specifications:
| Interfaces/Ports: |
1 x 1000BASE-LX LAN |
| Connector Type: |
DUPLEX LC |
| Cabling Options: |
62.5 µm Multi-mode Fiber 1000Base-SX
50 µm Multi-mode Fiber 1000Base-SX
9 µm Single-mode Fiber 1000Base-LX |
| Distance Support: |
Up To 10KM |
| Data Transfer Rate: |
1 Gbps Gigabit Ethernet |
| Management: |
DOM |
| Frequency: |
1310nm |
| Temperature: |
-5°C to 85°C Operating Case Temperature
-40°C to 85°C Storage Temperature |
| Form Factor: |
SFP (Small Form Factor Pluggable) MSA Compliant |
| Additional Information: |
Hot Swappable |
| Standard Warranty: |
Lifetime Replacement Warranty |
|
|
1000BASE-ZX SFP transceiver module SMF, 1550-nm wavelength, extended
operating temperature range and DOM support
Our Part Number:
MSSFP-GE-Z-ENC-18
OEM Part Number:
SFP-GE-Z
WEB PRICE EACH:
$281.00
|
Transceiver Specifications:
1000BASE-ZX SFP transceiver module SMF, 1550-nm wavelength, extended
operating temperature range and DOM support
| Interfaces/Ports: |
1 x 1000BASE-ZX LAN |
| Connector Type: |
DUPLEX LC |
| Cabling Options: |
9 µm Single-mode Fiber 1000Base-ZX |
| Distance Support: |
Up To 70KM |
| Data Transfer Rate: |
1 Gbps Gigabit Ethernet |
| Management: |
DOM |
| Frequency: |
1550nm |
| Temperature: |
-5°C to 85°C Operating Case Temperature
-40°C to 85°C Storage Temperature |
| Form Factor: |
SFP (Small Form Factor Pluggable) MSA Compliant |
| Additional Information: |
Hot Swappable |
| Standard Warranty: |
Lifetime Replacement Warranty |
|
100BASE-FX SFP Transceiver module for MMF, 2km 1310nm LC Connector
Our Part Number:
MSGLC-FE-100FX-ENC-18
OEM Part Number:
GLC-FE-100FX
WEB PRICE EACH:
$145.00
|
| Product Description: |
100BASE-FX SFP Transceiver module for MMF, 2km 1310nm LC Connector |
|
100BASE-LX SFP Transceiver module for SMF 1310nm 10KM Reach for Fast
Ethernet Ports LC connector
OurPart Number:
MSGLC-FE-100LX-ENC-18
OEM Part Number:
GLC-FE-100LX
WEB PRICE EACH:
$170.00
|
100BASE-LX SFP Transceiver module for SMF
1310nm 10KM Reach for Fast Ethernet Ports LC connector |
100BASE-ZX SFP Transceiver module for SMF 1550nm 80km LC connector
Our Part Number:
MSGLC-FE-100ZX-ENC-18
OEM Part Number:
GLC-FE-100ZX
WEB PRICE EACH:
$299.00
|
Product Information:
| Product Description: |
100BASE-ZX SFP Transceiver module for SMF 1550nm 80km LC connector |
|
CWDM 1470-nm SFP; Gigabit Ethernet and 1 and 2 Gb Fibre Channel
Our Part Number:
MSCWDM-SFP-1470-ENC-18
OEM Part Number:
CWDM-SFP-1470
WEB PRICE EACH:
$299.00
|
Transceiver Specifications:
CWDM 1470-nm SFP; Gigabit Ethernet and 1 and 2 Gb Fibre Channel
| Interfaces/Ports: |
1 x 1000BASE CWDM |
| Connector Type: |
DUPLEX SC |
| Cabling Options: |
9 µm Single-mode Fiber 1000Base-CWDM |
| Distance Support: |
Up To 80KM |
| Data Transfer Rate: |
1/2 Gbps Gigabit Ethernet/Fibre Channel |
| Management: |
DOM |
| Frequency: |
1470nm |
| Temperature: |
0°C to 70°C Operating Case Temperature
-40°C to 85°C Storage Temperature |
| Form Factor: |
SFP (Small Form Factor Pluggable) MSA Compliant |
| Additional Information: |
Hot Swappable |
| Standard Warranty: |
Lifetime Replacement Warranty |
|
CWDM 1490-nm SFP; Gigabit Ethernet and 1 and 2 Gb Fibre Channel
Our Part Number:
MSCWDM-SFP-1490-ENC-18
OEM Part Number:
CWDM-SFP-1490
WEB PRICE EACH:
$333.00
|
Transceiver Specifications:
CWDM 1490-nm SFP; Gigabit Ethernet and 1 and 2 Gb Fibre Channel
| Interfaces/Ports: |
1 x 1000BASE CWDM |
| Connector Type: |
DUPLEX LC |
| Cabling Options: |
9 µm Single-mode Fiber 1000Base-CWDM |
| Distance Support: |
Up To 80KM |
| Data Transfer Rate: |
1/2 Gbps Gigabit Ethernet/Fibre Channel |
| Management: |
DOM |
| Frequency: |
1490nm |
| Temperature: |
0°C to 70°C Operating Case Temperature
-40°C to 85°C Storage Temperature |
| Form Factor: |
SFP (Small Form Factor Pluggable) MSA Compliant |
| Standard Warranty: |
Lifetime Replacement Warranty |
|
CWDM 1510-nm SFP; Gigabit Ethernet and 1 and 2 Gb Fibre Channel
Our Part Number:
MSCWDM-SFP-1510-ENC-18
OEM Part Number:
CWDM-SFP-1510
WEB PRICE EACH:
$333.00 |
Transceiver Specifications:
CWDM 1510-nm SFP; Gigabit Ethernet and 1 and 2 Gb Fibre Channel
| Interfaces/Ports: |
1 x 1000BASE CWDM |
| Connector Type: |
DUPLEX LC |
| Cabling Options: |
9 µm Single-mode Fiber 1000Base-CWDM |
| Distance Support: |
Up To 80KM |
| Data Transfer Rate: |
1/2 Gbps Gigabit Ethernet/Fibre Channel |
| Management: |
DOM |
| Frequency: |
1510nm |
| Temperature: |
0°C to 70°C Operating Case Temperature
-40°C to 85°C Storage Temperature |
| Form Factor: |
SFP (Small Form Factor Pluggable) MSA Compliant |
| Additional Information: |
Hot Swappable |
| Standard Warranty: |
Lifetime Replacement Warranty |
|
CWDM 1530-nm SFP; Gigabit Ethernet and 1 and 2-Gb Fibre Channel
Our Part Number:
MSCWDM-SFP-1530-ENC-18
OEM Part Number:
CWDM-SFP-1530
WEB PRICE EACH:
$333.00 |
Transceiver Specifications:
CWDM 1530-nm SFP; Gigabit Ethernet and 1 and 2-Gb Fibre Channel
| Interfaces/Ports: |
1 x 1000BASE CWDM |
| Connector Type: |
DUPLEX LC |
| Cabling Options: |
9 µm Single-mode Fiber 1000Base-CWDM |
| Distance Support: |
Up To 80KM |
| Data Transfer Rate: |
1/2 Gbps Gigabit Ethernet/Fibre Channel |
| Management: |
DOM |
| Frequency: |
1530nm |
| Temperature: |
0°C to 70°C Operating Case Temperature
-40°C to 85°C Storage Temperature |
| Form Factor: |
SFP (Small Form Factor Pluggable) MSA Compliant |
| Additional Information: |
Hot Swappable |
| Standard Warranty: |
Lifetime Replacement Warranty |
|
CWDM 1550-nm SFP; Gigabit Ethernet and 1 and 2 Gb Fibre Channel
Our Part Number:
MSCWDM-SFP-1550-ENC-18
OEM Part Number:
CWDM-SFP-1550
WEB PRICE EACH:
$333.00
|
Transceiver Specifications:
CWDM 1550-nm SFP; Gigabit Ethernet and 1 and 2 Gb Fibre Channel
| Interfaces/Ports: |
1 x 1000BASE CWDM |
| Connector Type: |
DUPLEX LC |
| Cabling Options: |
9 µm Single-mode Fiber 1000Base-CWDM |
| Distance Support: |
Up To 80KM |
| Data Transfer Rate: |
1/2 Gbps Gigabit Ethernet/Fibre Channel |
| Management: |
DOM |
| Frequency: |
1550nm |
| Temperature: |
0°C to 70°C Operating Case Temperature
-40°C to 85°C Storage Temperature |
| Form Factor: |
SFP (Small Form Factor Pluggable) MSA Compliant |
| Additional Information: |
Hot Swappable |
| Standard Warranty: |
Lifetime Replacement Warranty |
|
CWDM 1570-nm SFP; Gigabit Ethernet and 1 and 2 Gb Fibre Channel
Our Part Number:
MSCWDM-SFP-1570-ENC-18
OEM Part Number:
CWDM-SFP-1570
WEB PRICE EACH:
$333.00
|
Transceiver Specifications:
CWDM 1570-nm SFP; Gigabit Ethernet and 1 and 2 Gb Fibre Channel
| Interfaces/Ports: |
1 x 1000BASE CWDM |
| Connector Type: |
DUPLEX LC |
| Cabling Options: |
9 µm Single-mode Fiber 1000Base-CWDM |
| Distance Support: |
Up To 80KM |
| Data Transfer Rate: |
1/2 Gbps Gigabit Ethernet/Fibre Channel |
| Management: |
DOM |
| Frequency: |
1570nm |
| Temperature: |
0°C to 70°C Operating Case Temperature
-40°C to 85°C Storage Temperature |
| Form Factor: |
SFP (Small Form Factor Pluggable) MSA Compliant |
| Additional Information: |
Hot Swappable |
| Standard Warranty: |
Lifetime Replacement Warranty |
|
CWDM 1590-nm SFP; Gigabit Ethernet and 1 and 2 Gb Fibre Channel
OurPart Number:
MSCWDM-SFP-1590-ENC-18
OEM Part Number:
CWDM-SFP-1590
WEB PRICE EACH:
$333.00
|
Transceiver Specifications:
CWDM 1590-nm SFP; Gigabit Ethernet and 1 and 2 Gb Fibre Channel
| Interfaces/Ports: |
1 x 1000BASE CWDM |
| Connector Type: |
DUPLEX LC |
| Cabling Options: |
9 µm Single-mode Fiber 1000Base-CWDM |
| Distance Support: |
Up To 80KM |
| Data Transfer Rate: |
1/2 Gbps Gigabit Ethernet/Fibre Channel |
| Management: |
DOM |
| Frequency: |
1590nm |
| Temperature: |
0°C to 70°C Operating Case Temperature
-40°C to 85°C Storage Temperature |
| Form Factor: |
SFP (Small Form Factor Pluggable) MSA Compliant |
| Additional Information: |
Hot Swappable |
| Standard Warranty: |
Lifetime Replacement Warranty |
|
CWDM 1610-nm SFP; Gigabit Ethernet and 1 and 2 Gb Fibre Channel
Our Part Number:
CWDM-SFP-1610-ENC
OEM Part Number:
CWDM-SFP-1610
WEB PRICE EACH:
$333.00
|
Transceiver Specifications:
CWDM 1610-nm SFP; Gigabit Ethernet and 1 and 2 Gb Fibre Channel
| Interfaces/Ports: |
1 x 1000BASE CWDM |
| Connector Type: |
DUPLEX LC |
| Cabling Options: |
9 µm Single-mode Fiber 1000Base-CWDM |
| Distance Support: |
Up To 80KM |
| Data Transfer Rate: |
1/2 Gbps Gigabit Ethernet/Fibre Channel |
| Management: |
DOM |
| Frequency: |
1610nm |
| Temperature: |
0°C to 70°C Operating Case Temperature
-40°C to 85°C Storage Temperature |
| Form Factor: |
SFP (Small Form Factor Pluggable) MSA Compliant |
| Additional Information: |
Hot Swappable |
| Standard Warranty: |
Lifetime Replacement Warranty |
|
Not Responsible for errors in print, verify all data with us
or manufacturer. Terms & Conditions of sale apply, for a copy contact us.
Products may be discontinued without notice. All Data is
Subject to Change Without Notice.
OnLine Order
