WIND TURBINE TRAY WIRE CABLE UL TYPE WTTC APPROVED FOR USE IN WIND TURBINE APPLICATIONS UNSHIELDED 1000V

1-800-843-6036

 Email Us

   OnLine Order

Supported Browsers IE, SAFARI, CHROME

                                                           12, 14, 10, 16, 18, AWG GAUGE, 12AWG, 14AWG, 10AWG, 16AWG, 18AWG

UL TYPE WTTC WIRES CABLES: CONSTRUCTION  FLEXIBLE STRANDED BARE COPPER. PVC/NYLON INSULATION, BINDER TAPE, RIPCORD. PVC JACKET. JACKET COLOR: BLACK

COMPLIANCE:  INDUSTRY: UL 2277 TYPE WTTC, UL 1277, UL 1581, UL 83, UL 66 NEC TYPE TFN CONDUCTORS (16 & 18 AWG), NEC TYPE THHN/THWN CONDUCTORS (14 -10 AWG), NEMA WC-70/ ICEA S-95-658, UL 1063 TYPE MTW. FLAME TESTS: UL1277, DP-1, UL1685, IEEE 1202, CSA FT-4, ICEA T-29-520

APPLICATIONS:  APPROVED FOR WET OR DRY LOCATIONS, SUNLIGHT RESISTANT - RATED 90C DRY, 75C WET TO -40C. APPROVED FOR USE IN WIND TURBINE APPLICATIONS




 12, 14, 10, AWG GAUGE, 12AWG, 14AWG, 10AWG

No. of Cond. AWG STRAND Approximate NOMINAL O.D.

INCHES

Approx. Net Weight [Lbs.]

 Per 1000 FT

UNSHIELDED 14 AWG MULTI CONDUCTOR

3 14 41/30 0.345



88
4 14 41/30 0.370



110
5 14 41/30 0.405



122
7 14 41/30 0.435



170
8 14 41/30 0.510



220
12 14 41/30 0.590



308
18 14 41/30 0.645



435
25 14 41/30 0.765



590
UNSHIELDED 12 AWG MULTI CONDUCTOR
4 12 65/30 0.435



150
5 12 65/30 0.480



174
7 12 65/30 0.570



242
UNSHIELDED 10 AWG MULTI CONDUCTOR
4 10 105/30 0.540



255
5 10 105/30 0.590



310
7 10 105/30 0.660



399





18AWG & 16AWG

No. of Cond. AWG STRAND Approximate NOMINAL O.D.

INCHES

Approx. Net Weight [Lbs.]

 Per 1000 FT

UNSHIELDED 18 AWG MULTI CONDUCTOR

3 18 19/30 0.295



58
4 18 19/30 0.350



70
7 18 19/30 0.395



84
8 18 19/30 0.440



98
9 18 19/30 0.445



112
12 18 19/30 0.455



167
18 18 19/30 0.570



251
25 18 19/30 0.660



310
50 18 19/30 0.890



645

UNSHIELDED 16 AWG MULTI CONDUCTOR

3 16 26/30 0.310



62
4 16 26/30 0.340



80
5 16 26/30 0.375



96
7 16 26/30 0.390



112
8 16 26/30 0.425



130
9 16 26/30 0.470



153
12 16 26/30 0.505



215
16 16 26/30 0.595



270
18 16 26/30 0.620



290
25 16 26/30 0.700



400
41 16 26/30 0.930



625
50 16 26/30 0.980



760
